| Part No | 90NB0WR1-M009T0 |
| Model Name | TP3402ZA-KN234W |
| |
| EAN Code | 4711387160664 |
| UPC Code | 197105160668 |
| |
| Operating System | Windows 11 Home - ASUS recommends Windows 11 Pro for business |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| LCD cover-material | Aluminum |
| LCD cover-color | Quiet Blue |
| Top case-material | Plastic |
| Top case-color | Quiet Blue |
| Bottom case-material | Plastic |
| Bottom case-color | Quiet Blue |
| Military grade | N/A |
| Touch Panel | Touch screen |
| Panel Size | 14.0-inch |
| Resolution | 2.8K (2880 x 1800) OLED 16:10 aspect ratio |
| Refresh rate | 90Hz refresh rate |
| Brightness | 400nits |
| Peak Brightness | 500nits HDR peak brightness |
| Color gamut | 100% DCI-P3 color gamut |
| Gamut mapping | Yes |
| Contrast ratio | 1,000,000:1 |
| VESA CERTIFIED Display HDR | VESA CERTIFIED Display HDR True Black 500 |
| Color depth | 1.07 billion colors |
| Pantone | PANTONE Validated |
| Glare | Glossy display |
| Low blue light | 65% less harmful blue light |
| T?V Rheinland-certified | TÜV Rheinland-certified |
| Screen-to-body ratio | 85 ? |
| Processor | Intel® Core™ i3-1220P Processor 1.1 GHz (12M Cache, up to 4.4 GHz, 10 cores) |
| Chipset | N/A |
| Discrete/Share | Share |
| Intergrated GPU | Intel® UHD Graphics |
| Disclaimer for Intel Iris Xe | *Intel Iris X? Graphics is only available in models with Intel® Core™ i5/i7/i9 processors and dual-channel memory. |
| VRAM | N/A |
| How to upgrade memory | Upgradable; Need to remove bottom/top case |
"| Expansion Slot(includes used) | 1x DDR4 SO-DIMM slot
1x M.2 2280 PCIe 3.0x4 |
"
| On board memory | 4GB DDR4 on board |
| DIMM Memory | 4GB DDR4 SO-DIMM |
| Total System Memory | DDR4 8GB |
| Disclaimer for memory | *Dual-channel memory support requires at least one SO-DIMM module. |
| Storage | 256GB M.2 NVMe™ PCIe® 3.0 SSD |
| Front-facing camera | 1080p FHD camera ; With privacy shutter |
| Wireless | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5 |
| NumberPad | Support NumberPad |
| ScreenPad? | N/A |
| FingerPrint | N/A |
"| I/O ports | 1x USB 2.0 Type-A
1x USB 3.2 Gen 2 Type-A
1x Thunderbolt™ 4 supports display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x DC-in |
"
"| Audio | Smart Amp Technology
Built-in array microphone
harman/kardon (Mainstream) |
"
| Voice control | with Cortana voice-recognition support |
| AC Adapter | ?4.5, 65W AC Adapter, Output: 19V DC, 3.42A, 65W, Input: 100~240V AC 50/60Hz universal |
| Battery | 70WHrs, 3S1P, 3-cell Li-ion |
| Replaceable Battery | No |
| Keyboard type | Backlit Chiclet Keyboard |
| Dimension (WxHxD) | 31.32 x 22.76 x 1.89 ~ 1.89 cm |
| Weight (with Battery) | 1.50 kg |
| Weight (without Battery) | 1.40 kg |
"| Security | McAfee® LiveSafe™
Computrace ready from BIOS
Trusted Platform Module (Firmware TPM) |
"
"| MyASUS feature | System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
Link to MyASUS
TaskFirst
Live update
ASUS OLED Care
AI Noise Canceling
Wi-Fi Rangeboost |
"
"| Built-in Apps | MyASUS
ScreenXpert
GlideX |
"
"| Adobe Creative Cloud Hard Bundle | One-Month Membership of Adobe Creative Cloud All Apps, Individual.
The redemption duration from September 15, 2021 to November 15, 2022. |
"
| Included in the Box | Stylus (ASUS Pen 2.0 SA203H-MPP2.0 support) |
| Reparability Index (for France) | 6.4 |
| |
| Záruka | Celosvetová záruka na hardvér 2 roky, 1 rok záruka na batériový článok |
| Asus Service Hotline: |
| SR: +421 232 162 621 |
| online: http://rma.asus.de/rma_cz |
